NIETZ MMA Series Welding Machine (MMA 500SiC)
CODE: NZWPMMA500SIC
Product Description:
Product Description:
Model: MMA500SiC
Invertor Technology: Sillicon Carbide Power Technology
Net Weight: 21 kg
Machine Dimension: 500 x 265 x 475 ±
MMA 500SiC welding machine features advanced inverter technology and a dual-station design, allowing two welders to work simultaneously from a single machine. Portable, efficient, and reliable for high-quality, safe welds.
Key Features:
Dual Operator Capability (Max 250A per Output)
High Output up to 500A
Lightweight Industrial Design
Heavy-Duty Cycle Performance
Wide Input Voltage Range (±15%)
Stable ARC Performance
High Power Factor (0.93)
High Efficiency (85%)
Multiple Protection Functions
Easy Maintanance Design
Standard Accessories:
Earth Clamp with 3m cable 300A X2
Electrode Holder with 3m cable 300A
Electrode Holder with 3m cable 500A
Technical Data:
Input Voltage (V): AC380V-50/60Hz
Input Power (KW): 25.3
Rated Input Current (A): 38.4
Output Current Range (A): 30-500 ±10%
Rated Output Voltage (V): 40
Duty Cycle (%): 100@500A
Power / Insulation Grade: IP21 S/F
Welding Process: MMA
Machine Dimension: 545 x 448 x 265mm ±
Packing Dimension: 608 x 565 x 360mm ±
